7.2-CHANNEL NETWORK AV Receiver

立即搶購

商品說明

Power Output (8 Ω, 20 Hz-20 kHz, FTC)80W / Channel (8 Ω)

Dynamic Power160W / Channel (3 Ω)
125W / Channel (4 Ω)
85W / Channel (8 Ω)

THD (Total Harmonic Distortion + Noise)0.08% (20 Hz-20 kHz, Half Power)

Input Sensitivity and Impedance200 mV / 47 k-Ω (LINE)
3.5 mV / 47 k-Ω (Phono MM)

Rated RCA Output Level and Impedance1 Vrms / 470 Ω (Subwoofer Pre Out)
200 mV / 2.3 k-Ω (Zone Line Out)
2.0 V / 2.3 k-Ω (Zone Pre Out)

Maximum RCA Output Level and Impedance4.6 V / 470 Ω (Pre Out)Phono Overload70 mV (MM 1 kHz, 0.5%)

Frequency Response5 Hz - 100 kHz / +1 dB-3 dB (Direct Mode)

Tone Control±10dB, 90 Hz (Bass)
±10dB, 7.5 kHz (Treble)

Signal-to-Noise Ratio106 dB (Line, IHF-A)
80 dB (Phono)

Speaker Impedance6 Ω - 16 Ω

Input Sensitivity / Output Level and Impedance1.0 Vp-p / 75 Ω (Component Y)
0.7 Vp-p / 75 Ω (Component Pb/Cb, Pr/Cr)
1.0 Vp-p / 75 Ω (Composite)

Tuning Frequency RangeFM 87.5 MHz - 107.9 MHz
530 kHz - 1,710 kHz

FM / AM Preset Memory40 Stations

Power SupplyAC 120 V, 60 Hz

Power Consumption460 W

Stand-by Power Consumption0.1 W

Dimensions (W X H X D)17 1/8" x 6 7/8" x 14 13/16"
435 x 174 x 376.5 mm

Weight20.7 lbs. (9.4 kg)

Box Dimensions (W X H X D)22 7/16" x 11 3/4" x 18 7/16"
570 x 298 x 469 mm

Box Weight28.7 lbs. (13.0 kg)
